5 Layers and Instruments | 81
If the assigned signal changes, the content updates automatically. For example,
the signal changes in the following cases:
The assigned signal is a calculated signal and you modify the calculation
formula. For more information, see "Defining Calculated Signals" on
page108.
You replace the measure file that contains the signal or other signals that
are used for calculating the assigned signal. For more information, see "To
replace a measure file" on page35.
You define a time offset. For more information, see "Defining a Time Offset
for a Measure File" on page37.
To see how you can use the Event List to navigate quickly between specific
events and display these in an oscilloscope, watch our video Finding Events.
You can perform the following actions:
"To define the Event List properties" below
"To scroll" below
"To navigate to the start or end of the time range" on the next page
"To move the synchronization timestamp" on the next page
"To show or hide header rows" on the next page
"To reorder columns" on the next page
"To change the decimals of the time column" on the next page
"To delete a signal" on the next page
To define the Event List properties
The complete set of configuration possibilities for this instrument is available in
the Properties docking window. There, the tooltips provide a detailed description
of the properties and their possible options.
1. Do one of the following:
In the instrument, click .
or
Select the instrument and press ALT+ENTER.
or
In the instrument, right-click and select Properties in the context menu.
To scroll
To quickly navigate to a specific timestamp, you can use the time slider. For more
information, see "Time Navigation and Synchronization" on page87. Altern-
atively, you can scroll by using the keyboard:
1. To move upwards, press the PAGE UP or CURSOR UP key.
2. To move downwards, press the PAGE DOWN or CURSOR DOWN key.
