5 Layers and Instruments | 82
To navigate to the start or end of the time range
1. To navigate to the start of the time range, press the HOME key.
2. To navigate to the end of the time range, press the END key.
To move the synchronization timestamp
In synchronized mode, the synchronization timestamp is highlighted in the
second row in blue. If the synchronization timestamp is located between the first
two rows, a blue line is displayed between these rows. For more information, see
"Synchronizing Instruments" on page88.
1. To move the synchronization timestamp, double-click a row.
or
2. Use the keyboard:
i. To select a row above the current synchronization timestamp, press
ALT+CURSOR UP.
ii. To select a row below the current synchronization timestamp, press
ALT+CURSORDOWN.
To show or hide header rows
To distinguish signals that have the same name but are coming from different
devices or different rasters, you can display the device, raster, or unit.
1.
In the toolbar, click or use the tab Instrument in the Properties Win-
dow.
A list of the default header rows appears.
2. To show or hide a header row, select or clear the checkbox of the respect-
ive name in the list.
To reorder columns
1. Move a column by dragging its column header to the new position within
the table header.
A line between the columns appears to indicate the new position.
2. Release the mouse button.
To change the decimals of the time column
1. Mark the time column for which you want to change the number of decimal
places.
2. In the toolbar, click one of the following icons:
l
To show more decimal places, click .
l
To show fewer decimal places, click .
To delete a signal
1. Right-click the signal name in the column header of the event list.
2. Select Remove Signal.
Alternatively, select the signal name and press DEL.
