5 Layers and Instruments | 51
Scatter Plot
The values of two signals are displayed as distribution of data samples
along the orthogonal value axes of the two signals. This instrument is
recommended for:
l
Detecting a correlation of signals
l
Getting an overview of the sample distribution
Table
The measurement data are displayed in a table. This instrument can be
used for:
l
Displaying non-numeric signals, as well as numeric signals
l
Inspecting the precise value of a signal for a specific timestamp
Statistical Data
Statistical properties of numeric signals are displayed, such as the aver-
age, minimum, maximum and standard deviation. This instrument is recom-
mended for:
l
Analyzing the statistical properties of numeric signals, which can give
insight into a signal's character and quality
l
Comparing multiple signals
Event List
In the event list, you can find certain events for analysis by evaluating a
search condition. This instrument is recommended for:
l
Finding all timestamps at which the value of a signal changes
l
Displaying a complete list of EVENT entries from an MDF file, like cal-
ibration activities, pause events, or comments
GPSMap
The GPS tracks are displayed in a map view. This instrument is recom-
mended for comparing and analyzing geographic data in relation to other
measured signals.
Video
In the video instrument you can display the video file recorded with the
INCAVideo-Integration add-on. This instrument is recommended for com-
bining a visual observation with the recorded measure data, especially for
analyzing in a synchronized mode with other instruments.
To use the Video instrument, you need a valid license provided with the
INCA Video-Integration add-on.
Battery Imbalance Table
The Battery Imbalance Table allows a quick evaluation of many comparable
signals. It is suited for identifying at one point in time the signals with the
highest or lowest deviation from the average value of all assigned signals.
