 Supports4x4locklevel,achieves4teamsx4multicardsaccesssettingoneach
door
 Eachdoorsupports10differentindependentdaysetting(SundaytoMonday,and3
kindsofcustomdaysetting).Eachdaycantake10timezoneswithminimum1
minuteduration
 Supportscomprehensiveaccessfeaturesincludinginterlock,area‐basedanti
passback,multi‐card/multi‐levelaccesscontrol,panicopen,remotedoorcontrol,
systemarm/disarm,multipledoorverificationmode,andfirstcard,etc.
 Multiplelanguagessupport:English,ChineseandRussian

1.2Overview
Thediagrambelowillustratesthecontrolleralongwithitsmaincomponentsandfunctions.



Figure1‐2

MainModule
Themainmodulecontrolsthefundamentalfunctionsofthecontroller,includingthe
built‐inbrowser‐basedsoftware,thesystemmanagement,thepowersupply,event
records,built‐inEthernetport,andcommunicationviaRS‐485port,twoalarminputsand
twoalarmoutputs.Themainmodulealsocontrolsthedoormodulesandalarmmodule.
No. Name Description
