EverFocus EFC304 - Determine the Hardware and Location

NAV IP Access controller
12
Obtainingafloorplanhelpstheinstallerdeterminewhatcomponentsneedtobe
installed,andwhere.Italsoisessentialindeterminingthelengthofcableneededto
connectreaderstothecontroller.Afloorplancanbeablueprintofthebuilding,a
design,orsimplyadrawingofthefacility.Anydocumentshowingthefootprintofthe
buildingcanbeused.Thedimensionsareimportanttonote,especiallywhen
determiningcablelengths.Afloorplanmaybeobtainedfromyourlocalcityhall.

2.1.2 Determine theHardwareandLocation
Determinewhichhardwaretouseandwhereitwillbeinstalled.Thisisthemostcrucial
stepinthepreparationstage.First,determinehowmanyaccesspoints,ordoors,needto
bemanagedbytheaccesscontrolsystem.Theseaccesspointswillcontrolthesecurityof
thefacility,andcanlimittheentryandexittoandfromanygivenareaofthebuilding.
Afterdecidingwhichdoorsneedtobecontrolled,theusermustalsodeterminethelevel
ofsecurityneededateachdoor.Therearemanywaystomanageeachdoor,using
differentresources.Theseresourcesinclude,butarenotlimitedto:proximityreaders,
magstripreaders,relays,andrequesttoexits.Afewcommondoorconfigurationsare
describedbelow:


 OneSetofNAVController+OneReader–TheBasicDoorEntryControl
ThemostbasicconfigurationinvolvesoneNAVcontroller,areaderandanelectricstrike.In
thisconfiguration,apersonpresentsacardtothereader,andiseithergrantedordenied
access.Theelectricstrikeunlocksifthesystemgrantsaccess.Anothervariationofthis
scenarioinvolvessettingthesystemuptomonitorwhetherthedoorisopen,whichallows
thesystemtoprotectagainstproppedopendoors,ordoorsbeingheldopenfortoolong.


 OneSetofNAVController+OneReader+OneDoorOpenButton–ControlofExit
Addingadooropenbuttontotheabovescenarioallowsthesystemtocontrolwhento
allowpeopletoexitthroughadoor.Thedooropenbuttonequipmentincludesabutton
whichhasto
bepressedwhenacardholderexits,oradoorsensor.Theequipmentshould
bearrangedonthesecuresideofthedoor.

Figure2‐1

