2.2.5 ConnectingtotheFire Alarm/AlarmOutput
Thealarmmodulesprovide8alarmoutputs.Youcanassignthecorrespondingrelay
statustothedifferentevents.Therearethreeterminals:COM,NOandNC.Thewiring
dependsonthealarmdevice.Pleasereadtheusermanualoftheexternal
alarmdevices
beforewiring.Followingareexamplesonconnectingthealarmoutputtothealarm
module.Fordetailsonpinassignment,pleasereferto1.6.2TerminalBlockandLEDson
AlarmModule.



Figure2‐15



Figure2‐16





Alarm
Device

C.terminal
N.C.terminal
N.C.
COM
Alarmmo dule
8
9

C.terminal
N.O.terminal
COM
N.O.
Alarmmo dule
7
8

AlarmDevice
Alarmsensor
Alarminput
GND
Alarmmodule
1
2
