EverFocus EFC304 - Specification

NAV IP Access controller
4
1 NetworkPort Connectstothenetwork.
2 LCDScreen
Displaysthecurrentstatusofthecontrollerandthe
menu.
3 Keypad Providesaninterfacetooperatethecontroller.
4 USB2.0Port Fordatabasebackup/restoreandfirmwareupgrade.
5 TerminalBlock
Connectstopower,alarminput/outputdevices,etc.
Pleasereferto1.6.1TerminalBlockandLEDsonMain
Module.
6 LEDs
Indicatesthecontrollerstatus.Pleasereferto1.6.1
TerminalBlockandLEDsonMainModule.

AlarmModule
Thealarmmoduleisusedtoextendthecontroller’salarmfunction,addingupto8alarm
inputsand8alarmoutputs.Eachcontrollercanonlyaddonealarmmodule.
No. Name Description
7 LEDs
Indicatesthealarmstatus.Pleasereferto1.6.2Terminal
BlockandLEDsonAlarmModule.
8 TerminalBlock
Connectstoalarminput/outputdevices.Pleasereferto
1.6.2TerminalBlockandLEDsonAlarmModule.

DoorModule
Thedoormoduleisusedtocontrolupto2readers,2relaysfordoorlocks,2relaysfor
alarmoutputs,otherdoorcontrolperipherals,andeventsignalstothemainmodule.
Eachcontrollercanaddupto4doormodules.
No. Name Description
9 LEDs
Indicatesthedoormodulestatus.Pleasereferto1.6.3
TerminalBlockandLEDsonDoorModule.
10 TerminalBlock
Connectstodoorsensors,doorlocks,request‐to‐exit
devicesandalarmoutputs.Pleasereferto1.6.3
TerminalBlockandLEDsonDoorModule.

1.3Specification
System
OperatingSystem Linuxembedded
Database Built‐in
Memory 512M
ManagementSoftware Built‐inbrowser‐basedsoftware,EFS2000,ENS2000
