EverFocus EFC304 - Definitions of Terminal Block and Leds; Terminal Block and Leds on Main Module

NAV IP Access controller

7
1.6 DefinitionsofTerminalBlockandLEDs
1.6.1 TerminalBlockandLEDsonMainModule

Figure1‐3
TerminalBlockDefinitions
No TerminalName Function No. TerminalName Function
1 AlarmIn0 Generalalarminput0 10 RS485_A SignalAofRS‐485bus
2 GND AlarminputGND 11 COMM_GND GNDofRS‐485
3 FireIn Firealarminput 12 RS485_B SignalBofRS‐485bus
4 AUXAlarmOutNo
Normallyopenpinof
auxiliaryalarmoutput
13 Power Powerinput
5 AUXAlarmOutCom
Commonpinof
auxiliaryalarmoutput
14 GND PowerGND
6 AUXAlarmOutNC
Normallyclosepinof
auxiliaryalarmoutput
15 BATT+ Batterypositivepin
7 AUXAlarmOutNo
Normallyopenpinof
mainalarmoutput
16 BATT‐ Batterynegativepin
8 AUXAlarmOutCom
Commonpinofmain
alarmoutput
17 USB USBport
9 AUXAlarmOutNC
Normallyclosepinof
mainalarmoutput
18 Ethernet Ethernetport


Figure1‐4

