NAV IP Access controller
8
LEDDefinitions
No Description No Description
1
Thepowerisonwhenthelight
ison.
3
Thedataisreceivedwhenthelight
ison.
2
Thefirealarmistriggered
whenthelightison.
4
Thedataistransmittedwhenthe
lightison.
1.6.2 TerminalBlockandLEDsonAlarmModule
Figure1‐5
No
Terminal
Name
Function
No
.
Terminal
Name
Function
1 Alarm1_In Alarmsignalinput1 19 Alarm5_In Alarmsignalinput5
2 GND GND 20 GND GND
3 Alarm2_In Alarmsignalinput2 21 Alarm6_In Alarmsignalinput6
4 Alarm3_In Alarmsignalinput3 22 Alarm7_In Alarmsignalinput7
5 GND GND 23 GND GND
6 Alarm4_In Alarmsignalinput4 24 Alarm8_In Alarmsignalinput8
7 Alarm1_NO Alarm1outputforNO 25 Alarm5_NO Alarm5outputforNO
8 Alarm1_COM
Alarm1outputin
common
26 Alarm5_COM
Alarm5outputin
common
9 Alarm1_NC Alarm1outputforNC 27 Alarm5_NC
Alarm5outputfor
normally‐close
10 Alarm2_NO Alarm2outputforNO 28 Alarm6_NO Alarm6outputforNO
11 Alarm2_COM
Alarm2outputin
common
29 Alarm6_COM
Alarm6outputin
common
12 Alarm2_NC Alarm2outputforNC 30 Alarm6_NC Alarm6outputforNC
13 Alarm3_NO Alarm3outputforNO 31 Alarm7_NO Alarm7outputforNO
14 Alarm3_COM
Alarm3outputin
common
32 Alarm7_COM
Alarm7outputin
common
15 Alarm3_NC Alarm3outputforNC 33 Alarm7_NC Alarm7outputforNC
16 Alarm4_NO Alarm4outputforNO 34 Alarm8_NO Alarm8outputforNO
