NAV IP Access controller

17

Figure2‐8

2.2.2 InstallingandConnectingtheReaders
Thereadersmustbemountedneareachdoorandconnecteddirectlytothedoor
module(s)inthecontroller.Eachdoormodulecancontroluptotworeaders.The
supportedreaderformatsareWiegandandRS‐232.

RS‐232Connection
ConnecttheRS‐232wiresfromthereadertotheterminalblockonthedoormodule.You
caneitherconnectthewiresfromthereadertoPin3~7(Door1)orPin19~23(Door2)
ontheterminalblock.

Figure2‐7

WiegandConnection
ConnecttheWiegandwiresfromthereadertotheterminalblockonthedoormodule.
YoucaneitherconnectthewiresfromthereadertoPin1~5(Door1)orPin17~21
(Door2)ontheterminalblock.
Red
Black
Y
ellow
Gray
Blue
EverAccess
#0
*
WXYZ
T U V
PQRS
7
M N O

65
J K L
4
G H I
3
D E F

A B C
2
1
98
23
22
21
20
19





Reader Ctrl
RX
TX
GND
+12
V
3
4
5
6
7
Doormodul e
