EverFocus EFC304 - Page 28

NAV IP Access controller

19

Fig ure2‐9

 MagneticLock
Connectthewiresfromthemagneticlocktotheterminalblockonthedoormodule.
YoucaneitherconnectthewirestoPin12and13(Door1)orPin28and29(Door2)
ontheterminalblock.

Figure2‐10

Note:
1. Themaximumcurrentoutputofthedoorlockrelayis5A.Ifthecurrentofthe
doorlockisoverthisvalue,anexternalpowerrelaywillberequired.
2. WhenusingaDCpowersourcetopowerthelock,connectthepositiveleadto
V+.WhenusinganACpowersource,theleadsareinterchangeable.

ConnectingtotheDoorSensor
Connectthewiresfromthedoorsensortotheterminalblockonthedoormodule.You
caneitherconnectthewirestoPin9and10(Door1)orPin25and26(Door2)onthe
terminalblock.

Doormodule
9
10
25
26
Doorsensor
GND
InputSignal
V
+
V
-
N.C.
COM
28
29
12
13
Doormodule
COM
N.O
.
V
-
V+
Doormodule
11
12
27
28
