Evolis Avansia User Manual

14
ä
Fitting the ink ribbon
To t a ink ribbon in the printing module, please proceed as follows:
Ê
Open the front cover.
Ë
Remove the ink ribbon cassette.
Ì
Load new ink ribbon in the cassette. Insert the spool spindle into the feed site (purple) holder. Unwind and load into the
shaft as shown. Finally, insert the spool spindle into the winding side holder, inserting the bottom first.
Í
Take up the ink ribbon slack. Turn the wheel as shown and take up the ribbon slack.
Î
Insert the ink ribbon cassette until a «click» is heard.
Ï
Put the Evolis electronic key in the key holder like shown page 13.
Ð
Close the front cover.
Ñ
Press the SET Key, when [Push SET Key] appears on the LCD.
When placing the ink ribbon down, prevent contamination adhering by placing it with the handle of the bottom.
If the ribbon is cut, carefully cut the ribbon with scissors. Use cellophane tape to join the ribbon. Then go back
to the step
Í
.
1
Ê Ë
Í
Ì
Ñ

Ï

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
