Evolis Avansia User Manual

15
ä
Changing the Transfer film
The transfert unit includes parts heated to high temperatures. Be careful not to put your fingers inside the
module. Follow the safety instructions.
Ê
Open the printer cover.
Ë
Remove the Transfer lm cassette.
Ì
Push down the pin on the top of the Transfer film cassette.
Í
Load Transfer film in the cassette. Insert the spool spindle into the feed side (grey) holder.Unwind and load onto the shaft
as shown. Finally insert the spool spindle into the winding side holder, inserting the bottom rst.
Î
Attach the pin on top of the Transfer lm cassette.
1
Ê Ë
Î
Ì
Í

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
