Evolis Avansia User Manual

45
4
4-2 Warnings and diagnosis
Although the Evolis printer was designed to work independently, keeping user involvement to a minimum, it may nonetheless prove useful
to gain some familiarity with the main warnings.
After clearing an error, pressing the SET key clears the errors, initializes the printer, and [Ready] will appear.
LCD Display Action required
Push SET Key Press the SET Key.
Feeder Empty Load cards into the card feeder.
Cover Open Correctly close the cover.
Low Temperature Ensure the environment temperature is at least 10°C and press SET Key.
Check Ribn/Film Conrm that the ink ribbon and Transfer lm are correctly loaded.
Remove Cards Remove the cards by rolating the Ejection Dial.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
