Evolis Avansia User Manual

21
ä
Loading the cards
Ê
Open the top cover and open the card feeder as shown.
Ë
Adjust the gauge setting to match the thickness of your cards
Ì
Hold the card retainer lever with your fingers and pull it right out.
 Insert the cards in the feeder as indicated, with the side to be printed facing to the left.
Î
Return the card retainer.
Ï
Close the top cover.
Load cards in order to start from the right side of the card feeding When printing starts the right-most card is
pulled into the printer. You can load card manually, one by one.
1
Ë
Ì
Í
Ê
Align
wheel
with
Marks
Lock Lever
Roller
Rubber
Card Case
Card Retainer

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
