Evolis Avansia User Manual

71
B
Appendix B
B1 - Encoding options
Some models of Evolis printers are equipped with encoding systems which are used to customise magnetic strips, and contact and
contactless smartcards.
Depending on the model, it is possible to install up to three types of encoder in the printer (magnetic strip, contact and contactless
smartcards).
B1a - MAGNETIC STRIP ENCODING
A printer tted with a magnetic encoder works in exactly the same way as a basic card printer. The Evolis encoder encodes the magnetic
strips in a single pass then runs a data check.
Congurable as high coercivity (HiCo) or low coercivity (LoCo) by a simple click in the Windows print driver, Evolis magnetic encoders are
however shipped with a default setting of high coercivity (HiCo), unless otherwise requested when placing the order.
ä
Location of the magnetic encoder
The magnetic encoder is a module tted in the factory. The read-write head is located in a module under the ip-over station. The
encoding sequence for a card is always carried out before the printing.
Use only magnetic strip cards that comply with ISO 7810 and ISO 7811 standards.
The magnetic strip must be moulded into the card to work properly.
Never use cards with a glued-on magnetic strip.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
