Evolis Avansia User Manual

72
ä
Card positioning
You can set the orientation of loading magnetic cards.
You can also change the settings by using the printer driver.
This setting is only available when the optional encoder unit is attached.
Ê
Switch from Normal mode to User mode.
Ë
Press the t Key until [Card Setup] is displayed. Then press the SET Key.
Ì
Press the t Key until [Set card side] is displayed. Then press the SET Key.
Í
Change the settings [Standard] or [Reverse] by using t/s Keys, then press the SET key.
Ê
Open the Top cover.
Ë
Open the card feeder.
Ì
Insert magnetic cards depending on the mode.
Í
Close the card feeder and the top cover.
The factory default setting is [Standard].
Printing on the magnetic strip terminal cannot be guaranteed.
[Standard] : [Reverse] :
B

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
