Evolis Avansia User Manual

16
Ï
Take up the Transfer lm slack. Turn the wheel at right and take up the lm slack.
Ð
Insert the Transfer lm cassette into the printer until a click is heard.
Ñ
Close the front cover.
Ò
Press the SET key when [Push SET Key] appears on the LCD.
When placing the Transfer lm down, prevent contamination adhering by placing it with the handle of the
bottom.
If the lm is cut, carefully trim the cut section with scissors. Use cellophane tape to join the lm. Then go back to
step
Î
page 15.
1
Ò
Ï Ð Ñ

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
