Evolis Primacy Service Manual

Primacy Service Manual
18 / 61
Spare parts list
Product
code
Name
Description
Step
CI010222
REJECT BOX
1
CI010214
ENCLOSURE SIDE
2
S10086
LCD AND CONTROL PANEL
WITH CABLE
3
S10123
UPPER RED FEEDER
For the Red model
4
S10124
UPPER BLUE FEEDER
For the Blue model
4
S10125
EXIT HOPPER RED FEEDER
For the Red model
4
S10126
EXIT HOPPER BLUE FEEDER
For the Blue model
4
S10092
FEEDER BELTS KIT
5
S10094
TIGHTING BELTS KIT
6
S10097
COMMON MOTOR
7-19-20
CI011190
ENCLOSURE BASE
8
S10121
FLIP OVER SENSOR
9
S10093
RIBBON BRAKING KIT
10
S10091
TRANSPORT BELTS KIT
11
S10087
RIBBON DETECTION KIT
12
S10098
STEPPER/FEEDER MOTOR
13
S10128
FLIP OVER MODULE
14
S10122
CLEANING ROLLER
15
CI010322
I/O SHIELD
16
SE010079
ENCLOSURE BOTTOM PLATE
17
S10114
MAIN BOARD : USB ETH USB HUB
18
S10096
STEPPER MOTOR
21
S10099
HEAD ROLLER KIT
22
S10088
FLEX SENSOR KIT
23
S10084
PRINT HEAD (KPE)
24
S10089
RIBBON SENSOR
25
CI010205
ENCLOSURE COVER
26
CI010206
ENCLOSURE BUTTOM
27
S10100
FAN KIT
28
S10085
PRINT HEAD CABLE
29
S10138
HEAD BRACKET
30
S10136
UNIVERSAL RIVET KIT
S10134
PRIMACY WIFI CARD
A5008
POWER SUPPLY
WITHOUT POWER CORD
A5017
DATA USB CABLE
USB-1.80M LENGHT
A5009
POWER CORD CABLE
EUROPEAN PLUG
A5010
POWER CORD CABLE
US PLUG
A5019
POWER CORD CABLE
UK PLUG
S10127
PACKAGING: BOX AND FOAM

Evolis Primacy Specifications

General

Resolution	300 dpi
Card Capacity Input	100 cards
Weight	4.02 kg (8.86 lbs)
Printing Technology	Dye-sublimation
Print Speed (YMCKO)	Up to 225 cards/hour
Card Capacity Output	100 cards
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards, ABS cards, Special varnished cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe, Contact and contactless smart card encoders
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	247 x 205 x 381 mm (9.72 x 8.07 x 14.99 in)
Power Supply	100-240 V, 50-60 Hz
