Primacy Service Manual
33 / 61
Step 11 – TRANSPORT BELTS KIT – S10091
1. Transport belt
a. First, be sure to have completely performed Step 8.
b. Remove the transport belt.
Picture 27: Transport Belt
2. Black Ribbon belt
a. First, be sure to have performed Step 2 without Step 2 -3.
b. Remove the Black Ribbon Belt, for more details refer to Step 10-5.
Picture 28: Black Ribbon Belt
1
2a

Evolis Primacy Specifications

General

Resolution	300 dpi
Card Capacity Input	100 cards
Weight	4.02 kg (8.86 lbs)
Printing Technology	Dye-sublimation
Print Speed (YMCKO)	Up to 225 cards/hour
Card Capacity Output	100 cards
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards, ABS cards, Special varnished cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe, Contact and contactless smart card encoders
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	247 x 205 x 381 mm (9.72 x 8.07 x 14.99 in)
Power Supply	100-240 V, 50-60 Hz
