Evolis Primacy Service Manual

Primacy Service Manual
54 / 61
Step 25 – RIBBON SENSOR – S10089
1. First, be sure to have completely performed Step 2-1.
2. Disconnect the sensor cable.
Picture 67: Ribbon Sensor - 1
3. Unclip the upper sensor support (a), unclip the lower sensor support and remove it (b).
Picture 68: Ribbon Sensor - 2
4. Remove the rivet and replace the sensor.
Picture 69: Ribbon Sensor - 3
2
3a
3b
4

Evolis Primacy Specifications

General

Resolution	300 dpi
Card Capacity Input	100 cards
Weight	4.02 kg (8.86 lbs)
Printing Technology	Dye-sublimation
Print Speed (YMCKO)	Up to 225 cards/hour
Card Capacity Output	100 cards
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards, ABS cards, Special varnished cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe, Contact and contactless smart card encoders
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	247 x 205 x 381 mm (9.72 x 8.07 x 14.99 in)
Power Supply	100-240 V, 50-60 Hz
