Evolis Primacy - Step 14 - Flip over Module - S10128; Picture 34: Flip Sensor; Picture 35: Flip Motor

Primacy Service Manual
37 / 61
Step 14 – FLIP OVER MODULE – S10128
1. First, be sure to have completely performed Step 8.
2. Press and turn at the same time the flip sensor support.
Picture 34: Flip Sensor
3. Remove the flip motor. ( For more details, refer to Step 13 )
Picture 35: Flip Motor
2
3
