Evolis Primacy - Advanced Cleaning Procedures

Primacy Service Manual
27 / 61
Step 7 – COMMON MOTOR – S10097 ( FEEDER)
1. First, be sure to have completely performed Step 5.
2. Remove the E-Ring and the pulley.
Picture 16: Feeder E-ring & pulley
3. On the other side disconnect and remove the cable.
Picture 17: Feeder Motor Cable
2
3
