Evolis Primacy Service Manual

Primacy Service Manual
4 / 61
This manual describes the disassembly operation and trouble shooting of Evolis Primacy printer. The
manual has been prepared in conformance with subsequent modifications and integrations and is
composed of:
 Safety regulations for use and maintenance
 General machine specifications
 Machine installation
 Operating modes
 Repairs and adjustments
 Electrical diagrams
Personnel assigned to operating the machine, in addition to being professionally trained for their
specific job must read the manuals, pay careful attention to safety regulations and the sections
pertinent to their job.
Individuals assigned to operating the machine are broken down as follows:
OPERATOR:
Assigned to loading the elements to process, visual inspection of the work cycle, unloading of
finished product and cleaning of the machine
MECHANICAL MAINTENANCE PERSONNEL:
Assigned to mechanical maintenance of the machine.
ELECTRICAL MAINTENANCE PERSONNEL:
Assigned to electrical maintenance of the machine.
NOTE:
EVOLIS shall not be held responsible for any non-conforming use of equipment of its
manufacture.

Evolis Primacy Specifications

General

Resolution	300 dpi
Card Capacity Input	100 cards
Weight	4.02 kg (8.86 lbs)
Printing Technology	Dye-sublimation
Print Speed (YMCKO)	Up to 225 cards/hour
Card Capacity Output	100 cards
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards, ABS cards, Special varnished cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe, Contact and contactless smart card encoders
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	247 x 205 x 381 mm (9.72 x 8.07 x 14.99 in)
Power Supply	100-240 V, 50-60 Hz
