Primacy Service Manual
41 / 61
Step 17 – ENCLOSURE BOTTOM PLATE – SE010079
1. First, be sure to have completely performed Step 8.
2. Press on the bottom plate clip (a) and push on the left (b) in the same time to remove
the module.
Picture 40: Bottom Plate
2
b
2
a
