Primacy Service Manual
55 / 61
Step 26 ENCLOSURE COVER CI010205
1. First, be sure to have completely performed Step 2-1.
2. With a screwdriver push on the cover clip and move it in the same time on each side.
Picture 70: Enclosure Cover - 1
3. Push backward the cover.
Picture 71: Enclosure Cover - 2
2
3
