Design and function
Organising welding tasks (Mode "JOB Manager")
100
099-000115-EW501
17.06.2015
5.16.2 Creating a new JOB in the memory or copying a JOB
Copying a pre-defined welding task from the fixed memory (JOBs 1 to 128) to the free memory
(JOBs 129-256):
It is normally possible to adjust all 256 JOBs individually. However, it is a good idea to assign
specific JOB numbers in the free memory (JOB 128 to 256) for specific welding tasks.
Operating
element
Action
Result
Display
x x
Select JOB Manager mode
Press until the “VOLT”
signal light is on
2 sec.
Select JOB Manager mode
1 x
Switch from “Load JOB” to “Copy JOB”
Select the required JOB number using the rotary
transducer (e.g. 150)
1 x
JOB has been copied to the free memory, machine
switches back to Display mode. The JOB can be
modified individually.
Current value and JOB
number displayed
