SunSDR2 DX User Manual
© 2020 Expert Electronics
ExpertSDR2 SOFTWARE DESCRIPTION
IF – tuning the frequency by moving the filter over the panorama.
RF Gain – RF Gain control.
CW Speed – CW Speed control.
RIT Offset – adjusting the RIT Offset.
XIT Offset – adjusting the XIT Offset.
In the right part of the menu you can see the main panel settings:
Enable - enable E-Coder panel control.
Use IF - frequency tuning by moving the filter over the panorama.
Use IF as RIT - tuning by IF when the RIT offset is on.
Use IF as XIT - tuning by IF when the XIT offset is on.
VFO B - enable sub-receiver.
Key Led - enable backlit keypad.
Encoder Led - enable backlit encoder.
Select RX1 or RX2 receiver.
No transfer PTT -
PTT to TCI – enable reroute of the PTT signal from the panel to TCI, has higher priority than
PTT to COM port.
PTT to COM port - rerouting of the PTT signal from the panel to the COM-port. Set the PTT to
COM port checkbox to enable rerouting the PTT signal.
Port name - COM-port number.
DTR/RTS - select the COM-port line, which is used for transferring the PTT commands. Set
one of the DTR/RTS line checkboxes to set it as the control line.
Volume - set the volume change step, per knob's clack.
Mic Gain - set the Mic gain change step, per knob's clack.
SQL - set the squelch threshold change step, per knob's clack.
Filter High - set the filter's high limit change step, per knob's clack.
Filter Low - set the filter's low limit change step, per knob's clack.
Filter Width - set the filter's width change step, per knob's clack.
Filter Shift - set the filter's shift change step, per knob's clack.
Drive - set the output level power change step, per knob's clack.
RF Gain - set the RF gain step, per knob's clack.
