TECHNICAL CHARACTERISTICS
6.3 Other
Characteristic
Value
Dimensions L x W x H, mm (inches)
190 x 170 x 80
(7.48 х 6.69 х 3.14)
Fan dimensions L x W x H, cm (inches)
140 x 140 x 25
(5.51 x 5.51 x 0.98)
Weight, kg (lbs)
1.8 (3.96)
DC voltage range in RX/TX, V
8...14.8 / 10...14.8
Recommended DC voltage, V
13.8
Current consumption RX/TX, A
1.2 / 24
Power consumption RX/TX, W
16.5 / 330
Operating temperature, °C (°F)
0...+50 (+32...+122)
Note:
· SunSDR2 DX cannot turn to TX when connected to a 15V power supply.
The max allowed power supply voltage for TX mode is 14.8V, if higher internal amplifier won't
work.
· The fan of the transceiver is controlled via the firmware, it should start rotating at ~40
Degrees.
There are 3 rotation modes: 40-50, 50-60, 60 and higher.
