DIPSTICK
®
2277 PARTS LIST
iv
It’s important that you learn to identify each part of the DS2277 Kit.
Please inspect each part carefully. If any parts are missing or appear damaged, call The Face Companies at
1-800-FNUMBER or (757-624-2121) immediately.
Cables, Software, Manuals and the Warranty are all found under the top foam lid of the Dipstick
®
case.
Item Description Units per Kit
1. Dipstick
®
unit with Moon Feet attached……………..………………………….. 1
2. 2277 Tablet and Clamp Assembly with beeper and LED Voltmeter…………… 1
3. Handle Assembly (2 Pcs) ………..……………………..…………………………. 1
4. Tape Measure…………………………………………………....…………………. 1
5. AC Adapter for Dipstick
®
…………………………………….…………………. 1
6. AC Adapter for 2277 Tablet……………………………..……….…….…..……… 1
7. Allen Wrenches, 7/64”, 1/8”, 5/32” & 1/16”…………………………..………….. 4
8. Open End Wrench, 7/16” x 3/8” ………………………….………………………. 1
9. Marking Crayon………………………………...…………………………………… 1
10. Dipstick
®
Connector Cable ("Coily Cord")…….………….……………………... 1
11. SD Card Reader ………………………………...…..………………………………… 1
12. Dipstick
®
Operator’s Manual………..………..……………..………………………. 1
13. Leg Extensions…………………………….........………..…………………..………. 1 pr
14. Software CD (RoadFace, RFCollect_2277).………………………………..……….... 1
To Next Page
