Installation manual
CNC 8060
CNC 8065
TOOL AND MAGAZINE MANAGEMENT.
7.
(REF: 1402)
·357·
Magazine-less system.
7.6.3 Basic PLC programming.
When executing the T function.
When executing the T function, the tool manager sends to the PLC, in the TMOPERATION
register, the code for the operation to be carried out.
DFU TMOPSTROBE AND (CPS TMOPERATION EQ 3) = SET GRTOSPDL
A tool change has been requested and TMOPERATION=3. The PLC has taken the tool
from ground to the spindle.
DFU TMOPSTROBE AND (CPS TMOPERATION EQ 4) = SET SPDLTOGR
A tool change has been requested and TMOPERATION=4. The PLC has taken the tool
from the spindle to ground.
DFU TMOPSTROBE AND (CPS TMOPERATION EQ 8) = SET SPDLTOGR
A tool change has been requested and TMOPERATION=4. The PLC has taken the tool
from the spindle to ground.
DFD SPDLTOGR AND (CPS TMOPERATION EQ 8) = SET GRTOSPDL
The manager has canceled the SPDLTOGR mark and TMOPERATION=8. The PLC has
taken the tool from ground to the spindle.
