Farmtrac 6050 E - Top View of Tractor

1 2 3 4 5 6 7
8
9
10
111213141516
27
Figure 15
3. Top View Of Tractor
1. Brake
2. Hand throttle control
3. Foot throttle accelerator
4. Diff lock
5 Main Gear lever
6. Parking Brake
7. DC Lever
8. PC Lever
9. DCV Lever
10. IPTO
11. Dual Speed PTO Control
12. PTO control Assembly
13. 4WD-2WD Lever
14. High Low Shuttle lever
15. Forward -reverse Shuttle
16. Clutch pedal
CONTROL INSTRUMENTS AND OPERATION
3.1. TOP VIEW OF TRACTOR
