3.3 WARNING SYMBOLS & INDICATION ON INSTRUMENT CLUSTER
CONTROLS, INSTRUMENTS AND OPERATION
Function
Symbol
Working Light
Front
Working Light
Rear
Sec. Trailer
Turn Indication
Trailer Turn
Indication
High Beam
Lower beam
Batter
Charge
Engine Oil
Pressure
Left Turn
Indicator
Color
Amber
Amber
Green
Green
Blue
Green
Red
Red
Green
2
1
Air Intake Filter
Contamination
Parking Brake
Glow Plug
Indicator
Fuel Reserve
Rotary Beacon
Neutral
Engine Coolant
Temperature
Red
Red
Yellow
Amber
Amber
Green
Red
P
N
Function
Symbol
OBD/MIL/
Diagnostic
Differential
Lock
PTO Clutch
Engine Protect
Lamp
Four Wheel
Drive
Engine Warning
Water in Fuel
Parking Light
Right Turn
Indicator
Color
Red
Yellow
Amber
Green
Amber
Red
Green
Diesel Particulate
Filter Regeneration
Enabled
Diesel particulate
filter inhibit switch
enabled
Amber
Green
Amber
Amber
