66
Figure 40.
1. Fuse Box Location
6.26 Fuse Box
Fuse Box is located on the right side above the engine
as shown in figure 36.
1
LUBRICATION AND MAINTENANCE CHART
Ÿ Cover the exhaust pipe opening.
Ÿ Preparing the Tractor for Use after Storage
Ÿ Inflate the tires to the correct pressure.
Ÿ Refill the fuel tank.
Ÿ Check the radiator coolant level.
Ÿ Check all oil levels.
Ÿ Install a fully charged battery.
Ÿ Remove the exhaust pipe covering.
Ÿ Start the engine and check that all instruments and
controls are functioning correctly.
Ÿ Drive the tractor without a load to ensure that it is
operating satisfactorily.
Ÿ Check the radiator coolant level. If the coolant is
within 200 hours of the next change, renew the
coolant. Run the engine for one hour to disperse the
inhibitor throughout the cooling system.
Ÿ Lubricate all grease fittings.
Ÿ Raise the lift linkage hydraulically and support the
lift arms in the fully raised position.
Ÿ Lightly coat all exposed hydraulic piston rods with
petroleum jelly (silica gel) e.g., power steering
cylinder rams, spool valves, etc.
Ÿ Remove the battery and store in a warm, dry
atmosphere. Recharge periodically.
Ÿ Raise the tractor and place supports under the
axles to take the weight off the tires.
Ÿ Block the clutch pedal in the fully depressed
position.
Ÿ Cover the exhaust pipe opening.
