Farmtrac 6050 E - Single Instrument Cluster

28
9
1. Engine coolant temperature gauge
2. Position Lamp
3. RPM Meter
4. Rotary Beacon Light
5. LH Turn Signal Indicator
6. MIL Lamp
7. Parking Light Indication
8. Engine Oil Pressure Warning Light
9. Clogging Sensor Light Indication
10 . Battery Indicator
11. Glow Plug Indicator
12. Trailer Turn Indicator 1
13. Differential Lock
14. 4 Wheel Driving Engagement Light
15. RH Turn Signal Indicator
16. Speed Meter
17. Lower Beam
18. Rear Working Light
19. Low fuel indication
20. Front Working Light
21. High Beam
22. Engine warning
23. Service Lamp
24. DPF Regeneration
25. Fuel Gauge
26. DPF Regeneration Inhibit Switch
Figure 16
3.2 Single Instrument Cluster
3
8
10
16
14
11
7
21
20
17
18
12
6
4
2
19
23
25
5
15
CONTROL INSTRUMENTS AND OPERATION
1
22
24
26
13
