FaroArm
®
Manual
January 2009
26
Chapter 1: Introduction to the FaroArm
®
When the laser is operating, the LEDs on the back of the unit illuminate.
See Figure 1-24 for the location of the laser emission indicator.
These LEDs also indicate the range of the laser to the target surface. For
more information, see “LEDs” on page 31.
CAUTION: VIEWING THE LASER OUTPUT WITH CERTAIN
OPTICAL INSTRUMENTS (EYE LOUPES, MAGNIFIERS, AND
MICROSCOPES, ETC.) WITHIN A DISTANCE OF 100 MM MAY
POSE AN EYE HAZARD.
Laser power up to 5 mW at 660 nm in a diverging beam could be
accessible in the interior of the FARO Laser Line Probe.
WARNING: DO NOT ATTEMPT TO OPEN THE LASER LINE
PROBE CASE. THERE ARE NO USER SERVICABLE PARTS.
Figure 1-24 Laser emission indicator
08M46E00_FaroArmUSB.book Page 26 Tuesday, February 17, 2009 1:42 PM
