FaroArm
®
Manual
January 2009
35
Chapter 1: Introduction to the FaroArm
®
2 Digitize eight points on a side of the calibration sphere with the Laser
Line Probe pointing in position #2, see Figure 1-33.
Digitize two points in the Near range
with the center of the laser. One point
on the upper half of the calibration
sphere and the other on the lower half.
Digitize two points in the Far range
with the center of the laser. One point
on the upper half of the calibration
sphere and the other on the lower half.
Digitize two points in the Center
range with the left side of the laser.
One point on the upper half of the
calibration sphere and the other on the
lower half.
Digitize two points in the Center
range with the right side of the laser.
One point on the upper half of the
calibration sphere and the other on the
lower half.
