Chapter 7: Technical Data
Deflection unit
Field of view
(vertical/horizontal): 300° / 360°
Step size
(vertical/horizontal): 0.009° (40,960 3D-Pixel on 360°) / 0.009° (40,960
3D-Pixel on 360°)
Max. vertical scan speed: 5,820rpm or 97Hz
Laser (optical transmitter)
Laser class: Laser class 1
Wavelength: 1550 nm
Beam divergence: Typical 0.19 mrad (0.011°)
(1/e, halfangle)
Beam diameter at exit: Typical 2.25 mm (1/e)
Data handling and control
Data storage: SD, SDHC™, SDXC™; 32GB card included
Scanner control: Via touchscreen display and WLAN
New WLAN access: Remote control, scan visualisation are possible on
mobile devices with Flash®
Multi-Sensor
Dual axis compensator: Levels each scan: Accuracy 0.015°; Range ± 5°
Height sensor: Via an electronic barometer the height relative to a
fixed point can be detected and added to a scan.
Compass
4
: The electronic compass gives the scan an orientation.
A calibration feature is included.
GPS: Integrated GPS receiver
Scanner power supply unit
AC Input Voltage: 100 - 240 V
AC Input Frequency: 50 - 60 Hz
Input current: 2.0 A
