Chapter 6: The Focus
3D
X 130 Controller Software
Factory Predefined Scan Profiles Overview
Managing Operators
(Home > Manage > Operators)
Indoor ..10m Indoor 10m...
Outdoor
...20m
Outdoor
20m...
Preview Object HD
Description
Scan indoors
where the dis-
tances from the
scanner to the
main objects of
interests are
less than 10m
Scan indoors
where the dis-
tances from the
scanner to the
main objects of
interests are
greater than
10m
Scan outdoors
where the dis-
tances from the
scanner to the
main objects of
interests are
less than 20m
Scan outdoors
where the dis-
tances from the
scanner to the
main objects of
interests are
greater than
20m
Capture a fast
and rough pre-
view scan of the
environment in
low resolution.
Scan certain
objects or areas
in very high
resolution. It is
recommended
to limit the scan
area to the
object or area of
interest, else the
scan might take
very long to
complete.
Resolution
1/8 1/5 1/5 1/4 1/16 1/2
Quality
3x 4x 4x 4x 4x 6x
Vertical Area
-60° - 90° -60° - 90° -60° - 90° -60° - 90° -60° - 90° -60° - 90°
Hor. Area
0° - 360° 0° - 360° 0° - 360° 0° - 360° 0° - 360° 0° - 360°
Inclinometer
ON ON ON ON ON ON
Compass
ON ON ON ON ON ON
Altimeter
ON ON ON ON ON ON
Color
ON ON ON ON OFF ON
Exposure
Metering
Mode
Horizon
Weighted
Horizon
Weighted
Horizon
Weighted
Horizon
Weighted
Even Weighted
Horizon
Weighted
Clear Contour
ON ON ON ON ON ON
Clear Sky
ON ON ON ON ON ON
Far Distance
Optimization
OFF OFF OFF ON OFF OFF
Point Distance
(mm/10m)
12.272 7.670 7.670 6.136 24.544 3.068
The following values refer to full area scans (360° horizontally / 300° vertically):
Resolution
(MPts)
11 28.2 28.2 44 2.8 176.0
Net Scan
Duration
(hh:mm:ss)
00:02:57 00:06:38 00:06:38 00:09:12 00:00:57 01:56:00
Scan File Size
(mb)
68.90 122.08 122.08 171.18 8.53 2216.66
Scan Size (Pt)
5156 x 2134 8248 x 3414 8248 x 3414 10310 x 4268 2578 x 1067 20622 x 8534
