Enhancing the Scanned Environment with Artificial
Targets
Before scanning, you should make sure that there will be enough reference
objects in the scans so that there will be no problems during the later registration
process. References, or targets, are used to register multiple individual scans that
are each on their own coordinate system, onto a single, aligned coordinate
system. Although scan registration in SCENE can be done purely on the basis of
natural targets, such as planes, walls, corners etc., we recommend to enhance the
28.4 1/5 3x 244 - 0:02:17 8,192
28.4 1/5 4x 122 - 0:04:35 8,192
28.4 1/5 6x 122 2x 0:18:20 8,192
11.1 1/8 2x 488 - 0:00:27 5,120
11.1 1/8 3x 244 - 0:00:54 5,120
11.1 1/8 4x 122 - 0:01:47 5,120
11.1 1/8 6x 122 2x 0:07:09 5,120
11.1 1/8 8x 122 4x 0:28:38 5,120
7.1 1/10 3x 244 - 0:00:34 4,096
7.1 1/10 4x 122 - 0:01:09 4,096
7.1 1/10 6x 122 2x 0:04:35 4,096
7.1 1/10 8x 122 2x 0:18:20 4,096
2.8 1/16 3x 244 - 0:00:13 2,560
2.8 1/16 4x 122 - 0:00:27 2,560
2.8 1/16 6x 122 2x 0:01:47 2,560
2.8 1/16 8x 122 4x 0:07:09 2,560
1.8 1/20 4x 122 - 0:00:17 2,048
1.8 1/20 6x 122 2x 0:01:09 2,048
1.8 1/20 8x 122 4x 0:04:35 2,048
0.7 1/32 4x 122 - 0:00:07 1,280
0.7 1/32 6x 122 2x 0:00:27 1,280
0.7 1/32 8x 122 4x 0:01:47 1,280
Resolution
Quality
Speed
(kpt/sec)
Noise
Compression
Net Scan
Time
(full scan)
pt/360°
Mio. Pts
(full scan)
Figure 5-28 Resolution and Quality
