Chapter 4: Parts and their Functions
LED behavior in case of errors:
Charge Level LED behavior
0 - 25% LED 2 is blinking blue, others are off
25 - 50% LED 2 is illuminating blue,
LED 3 is blinking blue,
LEDs 4 & 5 are off
50 - 75% LEDs 2 & 3 are illuminating blue,
LED 4 is blinking blue,
LED 5 is off
75 - 99% LEDs 2 to 4 are illuminating blue,
LED 5 is blinking blue
Fully charged LEDs 2 to 5 are illuminating blue
Error LED behavior
Temperature too low LED 2 is blinking red
Temperature too high LED 5 is blinking red
Battery is defective LEDs 2 to 5 are blinking red
Power Supply has under- or over
voltage
LED 1 is blinking red
