Appendix
Index List
Category Name
Index No.
DEC (HEX)
Sub
index
No.
Read/
Write
*1
Backup Format
Length
in
bytes
Default Setting details Remarks (Unit)
Detection
Setting
Teach status 59 (0x3B) 0 R UINT 1 Bit 0 to 3: Teach status
0: IDLE
1: 1-PT SUCCESS
2: 2-PT SUCCESS
3: 1/2-PT SUCCESS
4: WAITING FOR COMMAND
5: BUSY
7: ERROR
Bit 4: Teach status 1-PT TP1
0: Teach point 2 not taught
1: Teach point 2 successfully
taught
Bit 5: Teach ag SP1 TP2
0: Teach point 2 not taught
1: Teach point 2 successfully
taught
Bit 6: Teach ag SP2 TP1
0: Teach point 2 not taught
1: Teach point 2 successfully
taught
Detection
Settings
Qint. 1 SP1/SP2: Qint.
1 threshold 1
60 (0x3C) 1 R/W
✓
INT 2 100
Qint. 1 SP1/SP2: Qint.
1 threshold 2
2 R/W
✓
INT 2 200
Qint. 1 conguration:
Qint. 1 switchpoint logic
61 (0x3D) 1 R/W
✓
UINT 1 0 0x00: Light on/N.O.
0x01: Dark on/N.C.
Qint. 1 conguration:
Qint. 1 switchpoint
mode
2 R/W
✓
UINT 1 1 0x00: Not used
0x01: 1-point mode
0x02: 2-point zone mode
0x80: Edge height jump
Qint. 1 conguration:
Qint. 1 switchpoint
hysteresis
3 R/W
✓
UINT 2 5 1 to 99 Unit: %
Qint. 2 SP1/SP2: Qint.
2 threshold 1
62 (0x3E) 1 R/W
✓
INT 2 100
Qint. 2 SP1/SP2: Qint.
2 threshold 2
2 R/W
✓
INT 2 200
Qint. 2 conguration:
Qint. 1 switchpoint logic
63 (0x3F) 1 R/W
✓
UINT 1 0 0x00: Light on/N.O.
0x01: Dark on/N.C.
Qint. 2 conguration:
Qint. 2 switchpoint
mode
2 R/W
✓
UINT 1 1 0x00: Not used
0x01: 1-point mode
0x02: 2-point zone mode
0x80: Edge height jump
Qint. 2 conguration:
Qint. 2 switchpoint
hysteresis
3 R/W
✓
UINT 2 5 1 to 99 Unit: %
Identication Device/function name 64 (0x40) 0 R/W
✓
STRING 32 *******
Detection
Settings
Teach o󰀨set 90 (0x5A) 0 R/W
✓
INT 1 10 0 to 99 Unit: %
Setup edge height jump
Qint. 1: Cycle o󰀨set
93 (0x5D) 1 R/W
✓
UINT 1 10 1 to 255
Setup edge height jump
Qint. 1:
Minimum height jump
2 R/W
✓
UINT 2 100 0 to 9999
Setup edge height jump
Qint. 1:
Maximum height jump
3 R/W
✓
UINT 2 9999 0 to 9999
Setup edge height jump
Qint. 1:
Hysteresis
4 R/W
✓
UINT 2 5 1 to 9999
Setup edge height jump
Qint. 1: Jump direction
5 R/W
✓
UINT 1 2 0x00: Positive edge
0x01: Negative edge
0x02: Positive and negative edge
Setup edge height jump
Qint. 2: Cycle o󰀨set
94 (0x5E) 1 R/W
✓
UINT 1 10 1 to 255
Setup edge height jump
Qint. 2:
Min. height jump
2 R/W
✓
UINT 2 100 0 to 9999
Setup edge height jump
Qint. 2:
Max. height jump
3 R/W
✓
UINT 2 9999 0 to 9999
Setup edge height jump
Qint. 2:
Hysteresis
4 R/W
✓
UINT 2 5 1 to 9999
Setup edge height jump
Qint. 2: Jump direction
5 R/W
✓
UINT 1 2 0x00: Positive edge
0x01: Negative edge
0x02: Positive and negative edge
