Fastus D4RF Series - Specifications; Sensor Amplifier Specifications

6-2
Specications
6-1 Specifications
6-1-1 Sensor Amplifier Specifications
Type
Stand-alone unit
(IO-Link device)
Inter-connection main unit
Inter-connection
expansion unit
Model 1 output and
1 switchable
output/input
Cable type D4RF-T D4RF-TM D4RF-TS
Connector
type
D4RF-TC4 D4RF-TMC4 D4RF-TSC4
2 outputs and
1 input
Cable type D4RF-TD D4RF-TDM D4RF-TDS
Light source 4-element Red LED (Wavelength: 660 nm)
Response time 16 μs, 70 μs, 250 μs, 500 μs,
1 ms, 2 ms, 8 ms
Stand-alone use:
16 μs, 70 μs, 250 μs, 500 μs,
1 ms, 2 ms, 8 ms
Inter-connection use:
22 μs, 70 μs, 250 μs, 500 μs,
1 ms, 2 ms, 8 ms
22 μs, 70 μs, 250 μs, 500 μs,
1 ms, 2 ms, 8 ms
Teach Mode 1 point, 2 points, Auto, Through, 1-point Zone, 2-point Zone, Manual
Display Main display OLED display 128 x 22 pixel
Menu languages: English, Japanese, Korean, Simplified Chinese, Spanish
Indicators 2 x Output indicator (orange)
Power indicator (green): Lights up when power is on (Blinks during IO-Link communication
for stand-alone unit)
Interface Control output
*1
NPN/PNP, open collector or Push-pull selectable by setting
1 output: Max. 100 mA, 2 outputs: Max. 50 mA each/30 VDC residual voltage 1.8 V or less
External input Teach, Counter-reset, Emitter off, or Preset loading
*2
IO-Link Control output 1 is switchable
to IO-Link
—
IO-Link Revision 1.1 —
Baud rate COM 3 (230.4 kbps)
Number of process input
data bytes
4 bytes
Minimum cycle time 0.5 ms
Number of units with cross talk prevention — Response time 22 μs: 2 units, 70 μs: 3 units, 250 μs: 4 units,
500 μs: 9 units, 1 ms: 9 units, 2 ms: 12 units, 8 ms: 14 units
(including main unit)
Timer function On delay, Off delay, On/off delay, Pulse output, On delay pulse
Adjustable 1 to 30,000 ms
Output mode Light ON/Dark ON, selectable by setting
Number of connectable units — Max. 16 units (including main unit)
Connection type Cable type: 2 m, minimum bending radius: 4 × cable diameter
5 wires with 2-outputs and 1-input models
4 wires with 1-output and 1-switchable-output/input models
3 wires with 2-outputs and 1-input expansion models
2 wires with 1-output and 1-switchable output/input expansion models
Connector type: M8 4-pin connector
Insulation resistance 20 Megohm or more (with 500 VDC)
