Fastus D4RF Series - Dimensions

6-4
Specications
6-1-2 Dimensions
 Stand-alone Unit
z Connector model (D4RF-TC4)
S
R
2
1
R
S
Open angle approx.
135° and 180°
33.2
88
10.5
10.4
79.150.7
74.25
18.8 36.6
M8, 4-pin plug connector
2 × ø2.3
Unit: mm
z Cable models (D4RF-T, D4RF-TD)
10.4
Cable length: 2 m ø4.0
5 wires, 4 wires × 0.18 mm²
