Fastus D4RF Series - Service Data

6-8
Index List
6-2-3 Service Data
Category Name
Index No.
DEC (HEX)
Sub
index
No.
Read/
Write
*1
Backup Format
Length
in
bytes
Default Setting details Remarks (Unit)
System System command 2 (0x02) 0 W UINT 1 0x41: 1-point teach (threshold 1)
0x42: 1-point teach (threshold 2)
0x43: 2-point teach (teach point 1)
0x44: 2-point teach (teach point 2)
0x45: Through teach
0x47: Auto teach start
0x48: Auto Teach stop
0x4B: Zone teach
0x81: Setting reset
0x82: Restore factory settings
0xC0: Reset counter
0xC1: Preset counter
0xD0: Load preset number
0xD1: Save to preset number
0xD6: Zero set of measurement
value
0xD7: Zero reset of measurement
value
0xE4: Reset diagnostics parameter
General
Settings
Access Lock 12 (0x0C) 0 R/W
✓
UINT 2 0 Bit 01: Storage lock
Bit 02: Parameter lock
Bit 03: Key lock
Identication Vendor Name 16 (0x10) 0 R STRING 8 OPTEX FA
Product Name 18 (0x12) 0 R STRING 8 D4RF-TD
D4RF-T
D4RF-TC4
Product ID 19 (0x13) 0 R STRING 5 20529
20530
20531
Product Text 20 (0x14) 0 R STRING 26 Photoelectric
Fiber Sensor
Serial number 21 (0x15) 0 R STRING 8
YYWWNNNN Y=Year, W=CW,
N=Number
Hardware Version 22 (0x16) 0 R STRING 4
Firmware Version 23 (0x17) 0 R STRING 6
Application Specic Tag 24 (0x18) 0 R/W
✓
STRING 32 *******
Observation Device Status 36 (0x24) 0 R UINT 1 0x00: Device is OK
0x01: Maintenance required
0x02: Out of specication
0x04: Failure
Detailed Device Status 37 (0x25) 1 R UINT 9 Expressed in 3 bytes per set of
EVENT information currently
occurring
Event #1
n+0, n+1: Event code
0x1800: High temperature
(depends on high
temperature setting of
index 179, subindex 1)
0x1801: Low temperature
(depends on low
temperature setting of
index 179, subindex 2)
0x1802: Operating hours (depends
on operating hours setting
of index 179, subindex 3)
0x1803: Receiving light level
diagnostic
0x1804: Short-circuit on output
n+2: Event details
Bit 00 to 02: Source
(0: Unknown, 4: On application)
Bit 03: Reserved
Bit 04 to 05: T
ype
(1: Notication, 2: Warning, 3:
Failure)
Bit 06 to 07: Mode
(1: One-o󰀨, 2: Resolved, 3:
Occurred)
Same format as above for events
#2...3 thereafter.
Detection
Setting
T
each channel 58 (0x3A) 0 R/W UINT 1 0 0x00: default = Qint.1
0x01: Qint.1
0x02: Qint.2
