Initial Settings List
6-3 Initial Settings List
This section describes the factory default settings of this product.
When this product is reset ([SC] Reset - [SB] Factory reset/Setting reset), the settings return to the
parameters listed below.
Main menu Sub menu Default value
Description
S1 Output mode (N.O./ N.C.) — Light on Page 4-5
S3 Response time 250 μs Page 4-6
S4 Timer Not used Page 4-7
S6 Display P1 Display mode Value Page 4-9
P2 Hold display Off Page 4-11
P3 Brightness 100% Page 4-11
P4 Rotate display Off Page 4-11
P5 Invert display Off Page 4-12
P6 Alarm display Off Page 4-12
P7 Zeroing Not used Page 4-13
P8 Eco mode Off Page 4-13
P9 Stretch mode Off Page 4-13
PA Language English Page 4-14
S7 Detection D1 Hysteresis 5% Page 4-15
D2 Threshold mode Standard Page 4-16
D3 APC On Page 4-17
D4 ASC Off Page 4-17
D5 Emitter power Max Page 4-18
D6 Counter Off Page 4-19
D7 Set count 10 Page 4-21
D8 Edge direction Both Page 4-21
D9 Edge offset 2500 μs Page 4-22
DA Edge hys. 5 Page 4-22
S8 I/O O1 I/O polarity NPN Page 4-24
O2 Pin 2 setting Output 2 Page 4-25
O3 Pin 5 setting Output 2 Page 4-26
O4 Pin 2 setting Teach input Page 4-26
O5 Lock mode Lock all Page 4-27
O6 Preset setting — Page 4-27
O7 Load preset — Page 4-28
