GENERAL MT100 Multipoint Flow Meter
● When mounting the flow element into the process pipe, it is important that a lubricant/sealant is applied to the mating threads. A
lubricant/sealant compatible with the process conditions should be used. All connections should be tightened firmly. To avoid leaks do
not overtighten or cross-thread connections
Order Verification
● Verify the received hardware matches the purchased hardware and application requirements. Verify the Model number part number
on the instrument I.D. tag (e.g., MT100S – 2180…) matches the purchased Model number part number. See Equipment Nameplate
below for nameplate details.
● Review the Calibration requirements as specified on the Engineering Data Sheet in the documentation package. Verify the flow,
temperature and pressure limits meet the application requirements.
Hardware – Model Descriptions
MT100S – Single point insertion element with flow and temperature process output
MT100M – Multipoint element with flow and temperature process output
Documentation and Accessories
06EN003460 MT100 Installation, Operation, & Maintenance Manual (this manual)
06EN003461 MT100 Configuration Software Manual
Calibration Certification Documentation
PC Configuration Software and USB cable
Supplemental Manuals, Optional
06EN003472 MT100 F
OUNDATION Fieldbus Manual
06EN003474 MT100 PROFIBUS PA Manual
Equipment Nameplate
A nameplate is affixed to the local enclosure (flow element) and remote electronics enclosure (transmitter). In addition to the manufacturer
(FCI) identification, the nameplate shows the information listed below.
The nameplate details vary depending on the instrument’s specific build configuration as specified in the OIS (order
information sheet) and applicable approval ratings.
● Applicable enclosure ratings/agency approvals
● Model number (follows OIS block number information as specified in the order)
● Power input
● Wiring diagram drawing number
● Rated max. pressure
● Serial number
● Date of manufacture
● Tag numbers (components of system)
● Multilingual Caution notes
Fluid Components International LLC 2
