FCI MT100 User Manual

MT100 Multipoint Flow Meter INSTALLATION
C01289-1-1
Figure 2 – MT100M: Multipoint Flow Element Showing Flat Area, Flange Mount
Reference Flat
Markings
CUSTOMER
FLOW DIRECTION
Reference Flat
FLANGE CONNECTION
2-INCH 150 LB RF FLANGE,
316L SST PERANSI/ASM E B16.5
HORIZONTAL
VERTICAL
FLOW
FLOW
APPLICATIONS
APPLICATIONS
CUSTOMER SUPPLIED
INTERCONNECTING SIGNAL CABLE
C01408-1-1
Figure 3 – MT100S: Single Point Flow Element Showing Flat Area, Flange Mount
Fluid Components International LLC 7
