MT100 Multipoint Flow Meter GENERAL
Specifications
Instrument
■ Measuring Capability
■
Agency Approvals (Optional)
CE marking, CRN (pending, MT100S only)
FM/FMc:
Class I, Division 2, Groups A, B, C, and D
Class II/III, Division 2, Groups E, F, and G
Multi-point, averaging flow rate system for air and gases in large
diameter pipes and rectangular ducts; provides flow rate, totalized
flow, temperature.
■ Basic Style
MT100M:
Insertion with two or more sense points on one or more
mast-type flow element probes; minimum of two (2)
points per mast; maximum of eight (8) points on single
mast.
MT100S:
Insertion with up to 8 single-point flow elements.
■ Flow Measurement Range
MT100M:
0.25 SFPS to 150 SFPS [0,07 NMPS to 46 NMPS]
MT100S:
0.25 SFPS to 1000 SFPS [0,07 NMPS to 305 NMPS]
Air @ standard conditions, 70 °F and 14.7 psia [21,1 °C and 1,01325 bar(a)]
■ Temperature Measurement Range
-50 °F to 500 °F [-45 °C to 260 °C] or
-50 °F to 850 °F [-45 °C to 454 °C]
■ Media/Fluid
All air, gas and gas combinations that are compatible with the flow
element’s wetted materials.
■ Accuracy
Flow (MT100M)
±2% of reading, ±0.5% of full scale
Flow (MT100S)
±0.75% of reading, ±0.5% of full scale
Temperature
±2 °F [±1 °C]
■ Repeatability
Flow
±0.5% of reading
Temperature
±1 °F [±1 °C]
■ Temperature Coefficient (Flow)
With optional temperature compensation, valid from 10% to 100%
of full scale calibration
Maximum ± 0.015% of reading/°F up to 850 °C [± 0.03% of
reading/°C up to 454 °C]
■ Turndown Ratio
Normally factory set and field adjustable from 2:1 to 100:1 within
calibrated range; higher ratios possible with factory evaluation of
application.
■ Temperature Compensation
Standard: ±30 °F [± 16 °C]
Extended (optional): ±100 °F [± 55 °C]
■ Calibration
Performed using equipment traceable to NIST (US National
Institute of Standards and Technology) and ISO/IEC 17025
international standards for test lab quality systems.
ATEX:
II 3 G Ex nA IIC T6...T1 Gc
II 3 D Ex tc IIIC T85°C...T450°C Dc
IECE:
Ex nA IIC T6...T1 Gc, Ta = 65°C
Ex tc IIIC T85°C...T450°C Dc
Note: Refer to
APPENDIX D for T-Rating details.
■ CEMS Compliance (Optional)
US EPA CEMS:
40 CFR 60 and 40 CFR 75
USA EPA GHG:
40 CFR 98.34(c)(1)
Flow Element
■ Material of Construction
Mast-type
All-welded, 316L stainless steel
Single-point
All-welded, 316L stainless steel;
Hastelloy C-276 Optional
Choice of flow
– FP fast response with protective shroud
sensor design:
– FPC same as – FP plus flow conditioner/isolator tab
– S unshrouded for dirty or moist applications
■ Operating Temperature (Process)
Mast-type
-50 °F to 500 °F [-45 °C to 260 °C]
-50 °F to 850 °F [-45 °C to 454 °C]
Single-point
-40 °F to 500 °F [-40 °C to 260 °C]
-40 °F to 850 °F [-40 °C to 454 °C]
■ Operating Pressure (Process)
Mast-type
100 psig [6,9 bar(g)]
Design pressure to 500 psig/34 bar(g))
Single-point
Metal ferrule
1000 psig [70 bar(g)]
Teflon ferrule
150 psig [10 bar(g)] @200 °F/93 °C maximum
Fixed Connection
1000 psig [70 bar(g)]
(NPT)
Fixed Connection
per flange rating
(flanged)
■ Process Connections
Mast-type: 2″ male NPT; 3″ [DN50] or larger flanges
Single-point
Compression fittings: 3/4″ or 1″ male NPT, stainless steel with
adjustable Teflon ferrule or metal ferrule; or flanged tapped and
threaded for 3/4″ fitting. ANSI or DIN flanges.
Compression fitting not available with 850 °F / 454 °C
temperature service versions
Retractable packing glands: Low pressure 50 psig [3,5 bar(g)]
or medium pressure 500 psig [34 bar(g)] with graphite or Teflon
packing material; 1 1/4 ″ male NPT or ANSI or DIN flange
Teflon packing material required when process media is ozone,
chlorine or bromine
Fixed fittings: 1″ male NPT, ANSI flange or DIN flange
Fluid Components International LLC 3
