1. Installation
1-12
Festo Festo P .BE CP FB13-E-EN en 9910c
Cable specification as per EN 50170 (cable type A):
Characteristic impedance: 135-165 Ohm (3-20 MHz)
Capacitance per unit length:
<30 nF/km
Loop resistance:
>110 Ohm/km
Core diameter:
>0.64 mm
Core cross section:
>0.34 mm
2
1.4 Connecting the CP modules
Warning
S For connecting the CP modules to a string, use the
special CP cable from Festo (type KVI-CP-1-...).
S Please note that the total length of cable on a string
must not exceed 10 m.
Y o u will thereby avoid:
– faults in data exchange between the node and the con-
nected CP modules
Information on the connection procedure can be found in the
manual “CP System, installation and commissioning”.
